Embed Unity in Flutter

yagi_eng

Reference

Intro

Difficulty

Unity Player Settings

Android

iOS

Run example

delete borderRadius: BorderRadius.circular(20.0), to remove BorderRadius

lib/screens/simple_screen.dart

          shape: RoundedRectangleBorder(
            borderRadius: BorderRadius.circular(20.0),
          ),

Error

if crash happens when opening unity on flutter app on Android, use OpenGLES3 as Graphics APIs
Swift Compiler Error (Xcode): No such module 'UnityFramework'
- https://github.com/juicycleff/flutter-unity-view-widget/issues/373
- can't run on simulator, but can run on physical device
Runtime JAR files in the classpath should have the same version. These files were found in the classpath:
- working
  - https://stackoverflow.com/questions/71347054/flutter-build-runtime-jar-files-in-the-classpath-should-have-the-same-version-t
- not working

w: Runtime JAR files in the classpath should have the same version. These files were found in the classpath:
    /Users/yagi/.gradle/caches/modules-2/files-2.1/org.jetbrains.kotlin/kotlin-stdlib-jdk8/1.5.30/5fd47535cc85f9e24996f939c2de6583991481b0/kotlin-stdlib-jdk8-1.5.30.jar (version 1.5)
    /Users/yagi/.gradle/caches/modules-2/files-2.1/org.jetbrains.kotlin/kotlin-stdlib-jdk7/1.6.20/f8629f336bad4001c89e9cffa5ef3d4b5d0f5e22/kotlin-stdlib-jdk7-1.6.20.jar (version 1.6)
    /Users/yagi/.gradle/caches/modules-2/files-2.1/org.jetbrains.kotlin/kotlin-reflect/1.3.10/dd02865be0351707554b16a896b766b2396cdafa/kotlin-reflect-1.3.10.jar (version 1.3)
    /Users/yagi/.gradle/caches/modules-2/files-2.1/org.jetbrains.kotlin/kotlin-stdlib/1.7.10/d2abf9e77736acc4450dc4a3f707fa2c10f5099d/kotlin-stdlib-1.7.10.jar (version 1.7)
    /Users/yagi/.gradle/caches/modules-2/files-2.1/org.jetbrains.kotlin/kotlin-stdlib-common/1.7.10/bac80c520d0a9e3f3673bc2658c6ed02ef45a76a/kotlin-stdlib-common-1.7.10.jar (version 1.7)

Unity Player Settings

if turning Hide Navigation Bar on, lower part of screen become white when Unity starts.
if turning Hide Navigation Bar off and Render outside safe area on, transparent status bar shows up.
- if turning Hide Navigation Bar on and Render outside safe area on, the bar doesn't show up.

Notes

can't quit Unity process on this library, but can unload based on the flollowing.
- https://github.com/juicycleff/flutter-unity-view-widget/issues/447
- Start() is called even after reloading
can override custom loading screen on unity loading screen like the following.

  @override
  Widget build(BuildContext context) {
    return Scaffold(
      body: Stack(fit: StackFit.expand, children: <Widget>[
        UnityWidget(
          onUnityCreated: _onUnityCreated,
          onUnityMessage: _onUnityMessage,
        ),
        if (_showLoading)
          Container(
              color: Colors.white,
              child: Center(
                child: LoadingAnimationWidget.threeRotatingDots(
                  color: Colors.blue,
                  size: 50,
                ),
              )),
      ]),
    );
  }

  void _onUnityMessage(message) async {
    logger.i('Received message from unity: ${message.toString()}');

    String msgStr = message.toString();
    if (msgStr == 'CompleteToLoad') {
      await Future.delayed(const Duration(seconds: 1));
      setState(() {
        _showLoading = false;
      });
    }
  }
