Raspberry Pi 5にカメラを接続する
スイッチサイエンスで購入した
Raspberry Pi用魚眼レンズカメラモジュール(8MP / IMX219)を接続する。
を参考に。
つないでみて、
$ libcamera-still -n -o photo.jpg
[0:11:59.183961317] [2194] INFO Camera camera_manager.cpp:284 libcamera v0.2.0+120-eb00c13d
ERROR: *** no cameras available ***
いきなりエラー。
まず、カメラの認識から
$ libcamera-hello --list-camera
No cameras available!
認識してないのか・・・
camera_auto_detect=1 only works for genuine Pi cameras, which yours isn't.
(和訳: camera_auto_detect=1は純正のPiカメラにしか使えません。)
との事。
If you do not use an official Raspberry Pi camera, you need to configure the "config.txt " file. If you use the latest Bookworm system, you need to configure /boot/firmware/config.txt.
sudo nano /boot/config.txt
#If using the bookworm system
sudo nano /boot/firmware/config.txtFind "camera-auto-detect=1" and modify it to "camera_auto_detect=0".
At the end of the file, add the following setting statements according to the camera model.
IMX219 dtoverlay=imx219
和訳
公式のRaspberry Piカメラを使用しない場合は、"config.txt"ファイルを設定する必要があります。最新のBookwormシステムを使用する場合は、/boot/firmware/config.txtを設定する必要があります。
sudo nano/boot/config.txt
#bookwormシステムを使用している場合
sudo nano/boot/firmware/config.txt"camera-auto-detect=1"を探し、"camera_auto_detect=0"に変更します。
ファイルの最後に、カメラのモデルに応じて次の設定文を追加します。
IMX219 dtoverlay=imx219
公式サイトを確認。(初めから見ればよかった。)
sudo nano /boot/firmware/config.txt
#Find the line: camera_auto_detect=1, update it to:
camera_auto_detect=0
#Find the line: [all], add the following item under it:
dtoverlay=imx219,cam0
#Save and reboot.
rpicam-hello --list-cameras 0
色調の調整が必要。
カメラの情報取得
$ rpicam-hello --list-cameras
Available cameras
-----------------
0 : imx219 [3280x2464 10-bit RGGB] (/base/axi/pcie@120000/rp1/i2c@88000/imx219@10)
Modes: 'SRGGB10_CSI2P' : 640x480 [206.65 fps - (1000, 752)/1280x960 crop]
1640x1232 [41.85 fps - (0, 0)/3280x2464 crop]
1920x1080 [47.57 fps - (680, 692)/1920x1080 crop]
3280x2464 [21.19 fps - (0, 0)/3280x2464 crop]
'SRGGB8' : 640x480 [206.65 fps - (1000, 752)/1280x960 crop]
1640x1232 [83.70 fps - (0, 0)/3280x2464 crop]
1920x1080 [47.57 fps - (680, 692)/1920x1080 crop]
3280x2464 [21.19 fps - (0, 0)/3280x2464 crop]
赤みがどうしても取れないので、自動オートホワイトバランスを無効化して、手動で調整。ちょっと青みが強い気がするけど。
rpicam-jpeg --awbgains 0.90,1.60 --width 1640 --height 1232 --metering average --output test.jpg
Pythonで使いたい時は、 Picamera2
を使う。
$ apt list --installed | grep picamera2
python3-picamera2/stable,stable,now 0.3.18-1 all [installed]
既にインストール済みだった。
マニュアルはこちら。
tuning file のパス
カメラのチューニング?
4.6
the “target” field must read “pisp” に変更すれば、RPi 4のファイルを使える?
