UserDetailsServiceについての個人的なまとめ

◆UserDetailsServiceインターフェースのloadUserByUsernameメソッドをオーバーライドすることでDB認証が行える
→ ユーザー情報を取得するインターフェース。このインターフェースはDaoAuthenticationProviderによって利用されるユーザーDAOです。

◆一方で以下のような方法もある
UsernamePasswordAuthenticationFilterを継承して、AuthenticationProviderの実装クラスを作成した場合はAuthenticationProviderの実装クラスにてユーザ取得処理を実装する。

または、こんな感じでfileterからデフォルトのauthenticationManagerを利用する

MyAuthenticationFilter

    // 認証の処理
    @Override
    public Authentication attemptAuthentication(HttpServletRequest req,
                                                HttpServletResponse res) throws AuthenticationException {
        try {
            // requestパラメータからユーザ情報を読み取る
        	LoginForm userForm = new ObjectMapper().readValue(req.getInputStream(), LoginForm.class);
            return authenticationManager.authenticate(
                    new UsernamePasswordAuthenticationToken(
                            userForm.getUsername(),
                            userForm.getPassword(),
                            new ArrayList<>())
            );
        } catch (IOException e) {
            throw new RuntimeException(e);
        }
    }

AuthenticationManagerの実装クラス
(1)で認証処理を呼出す

	static final class AuthenticationManagerDelegator implements AuthenticationManager {

		private AuthenticationManagerBuilder delegateBuilder;

		private AuthenticationManager delegate;

		private final Object delegateMonitor = new Object();

		AuthenticationManagerDelegator(AuthenticationManagerBuilder delegateBuilder) {
			Assert.notNull(delegateBuilder, "delegateBuilder cannot be null");
			this.delegateBuilder = delegateBuilder;
		}

		@Override
		public Authentication authenticate(Authentication authentication) throws AuthenticationException {
			if (this.delegate != null) {
(1) 				return this.delegate.authenticate(authentication);
			}
			synchronized (this.delegateMonitor) {
				if (this.delegate == null) {
					this.delegate = this.delegateBuilder.getObject();
					this.delegateBuilder = null;
				}
			}
			return this.delegate.authenticate(authentication);
		}

		@Override
		public String toString() {
			return "AuthenticationManagerDelegator [delegate=" + this.delegate + "]";
		}

	}

AuthenticationManager(delegate)の実装クラスとなる。
(1)AuthenticationManager(delegate)の実装クラスではAuthenticationProvider#authenticateを呼出す

public class ProviderManager implements AuthenticationManager, MessageSourceAware, InitializingBean {

	private static final Log logger = LogFactory.getLog(ProviderManager.class);

	private AuthenticationEventPublisher eventPublisher = new NullEventPublisher();

	private List<AuthenticationProvider> providers = Collections.emptyList();

	protected MessageSourceAccessor messages = SpringSecurityMessageSource.getAccessor();

	private AuthenticationManager parent;

省略

	@Override
	public Authentication authenticate(Authentication authentication) throws AuthenticationException {
		Class<? extends Authentication> toTest = authentication.getClass();
		AuthenticationException lastException = null;
		AuthenticationException parentException = null;
		Authentication result = null;
		Authentication parentResult = null;
		int currentPosition = 0;
		int size = this.providers.size();
		for (AuthenticationProvider provider : getProviders()) {
			if (!provider.supports(toTest)) {
				continue;
			}
			if (logger.isTraceEnabled()) {
				logger.trace(LogMessage.format("Authenticating request with %s (%d/%d)",
						provider.getClass().getSimpleName(), ++currentPosition, size));
			}
			try {
(1)				result = provider.authenticate(authentication);
				if (result != null) {
					copyDetails(authentication, result);
					break;
				}
			}
			catch (AccountStatusException | InternalAuthenticationServiceException ex) {
				prepareException(ex, authentication);
				// SEC-546: Avoid polling additional providers if auth failure is due to
				// invalid account status
				throw ex;
			}
			catch (AuthenticationException ex) {
				lastException = ex;
			}
		}

Providerの基底クラスでは以下のように呼び出される
(1)で自身のretrieveUserを呼出してuserを取得しているが、ここは実装クラス(DaoAuthenticationProvider)の処理が走る

	@Override
	public Authentication authenticate(Authentication authentication) throws AuthenticationException {
		Assert.isInstanceOf(UsernamePasswordAuthenticationToken.class, authentication,
				() -> this.messages.getMessage("AbstractUserDetailsAuthenticationProvider.onlySupports",
						"Only UsernamePasswordAuthenticationToken is supported"));
		String username = determineUsername(authentication);
		boolean cacheWasUsed = true;
		UserDetails user = this.userCache.getUserFromCache(username);
		if (user == null) {
			cacheWasUsed = false;
			try {
(1)				user = retrieveUser(username, (UsernamePasswordAuthenticationToken) authentication);
			}
			catch (UsernameNotFoundException ex) {
				this.logger.debug("Failed to find user '" + username + "'");
				if (!this.hideUserNotFoundExceptions) {
					throw ex;
				}
				throw new BadCredentialsException(this.messages
						.getMessage("AbstractUserDetailsAuthenticationProvider.badCredentials", "Bad credentials"));
			}
			Assert.notNull(user, "retrieveUser returned null - a violation of the interface contract");
		}
		try {
			this.preAuthenticationChecks.check(user);
			additionalAuthenticationChecks(user, (UsernamePasswordAuthenticationToken) authentication);
		}

DaoAuthenticationProviderではUserDetailsServiceのloadUserByUsernameメソッドを呼び出している。
最初の「UserDetailsServiceインターフェースのloadUserByUsernameメソッドをオーバーライドすることでDB認証が行える」でオーバーライドしているのはココのメソッド
(1)UserDetailsService#loadUserByUsernameの呼出し

	@Override
	protected final UserDetails retrieveUser(String username, UsernamePasswordAuthenticationToken authentication)
			throws AuthenticationException {
		prepareTimingAttackProtection();
		try {
(1)			UserDetails loadedUser = this.getUserDetailsService().loadUserByUsername(username);
			if (loadedUser == null) {
				throw new InternalAuthenticationServiceException(
						"UserDetailsService returned null, which is an interface contract violation");
			}
			return loadedUser;
		}
		catch (UsernameNotFoundException ex) {
			mitigateAgainstTimingAttack(authentication);
			throw ex;
		}
		catch (InternalAuthenticationServiceException ex) {
			throw ex;
		}
		catch (Exception ex) {
			throw new InternalAuthenticationServiceException(ex.getMessage(), ex);
		}
	}
