【10日目】ベイズ最適化をやってみる【2021アドベントカレンダー】

2021/12/10に公開約8,300字

2021年1人アドベントカレンダー(機械学習)、10日目の記事になります。

https://qiita.com/advent-calendar/2021/solo_advent_calendar

テーマは ベイズ最適化 になります。

ベイズ最適化は、すでに持っている情報から、次にどの点を調べた方がいいかを判断し、実際に評価を行い、その結果を次の判断に利用するということを自動的に行う手法。
これにより、すべての点を評価しなくても、効率的に最適値にたどり着くことができる。

https://book.mynavi.jp/manatee/detail/id=59393
https://qiita.com/masasora/items/cc2f10cb79f8c0a6bbaa

本記事では理論的な解説は行わず、Optuna による最適化と、精度と処理時間を比較してみます。

Colab のコードはこちら Open In Colab

ベイズ最適化

from bayes_opt import BayesianOptimization
def lgb_eval(num_leaves, feature_fraction, bagging_fraction, max_depth, lambda_l1, lambda_l2, min_split_gain, min_child_weight):
    params = {
        'application':'regression',
        'num_iterations':4000,
        'learning_rate':0.05,
        'early_stopping_round':100,
        'metric':'rmse'
        }

    params["num_leaves"] = round(num_leaves)
    params['feature_fraction'] = max(min(feature_fraction, 1), 0)
    params['bagging_fraction'] = max(min(bagging_fraction, 1), 0)
    params['max_depth'] = round(max_depth)
    params['lambda_l1'] = max(lambda_l1, 0)
    params['lambda_l2'] = max(lambda_l2, 0)
    params['min_split_gain'] = min_split_gain
    params['min_child_weight'] = min_child_weight

    cv_result = lgb.cv(
        params,
        train_data,
        nfold=n_folds,
        seed=random_seed,
        stratified=False,
        verbose_eval =200,
        metrics=['rmse']
        )

    return max(cv_result['rmse-mean'])
lgbBO = BayesianOptimization(
                        lgb_eval,
                        {
                            'num_leaves': (24, 45),
                            'feature_fraction': (0.1, 0.9),
                            'bagging_fraction': (0.8, 1),
                            'max_depth': (5, 8.99),
                            'lambda_l1': (0, 5),
                            'lambda_l2': (0, 3),
                            'min_split_gain': (0.001, 0.1),
                            'min_child_weight': (5, 50)
                            },
                        random_state=SEED
)
def bayes_parameter_opt_lgb(X, y, init_round=15, opt_round=25, n_folds=5, random_seed=6, n_estimators=10000, learning_rate=0.05, output_process=False):

    # prepare data
    train_data = lgb.Dataset(
                            data=X_train_ce,  ### 適宜要修正
                            label=y_train,   ### 適宜要修正
                            free_raw_data=False
                            )

    # parameters
    def lgb_eval(num_leaves, feature_fraction, bagging_fraction, max_depth, lambda_l1, lambda_l2, min_split_gain, min_child_weight):

        params = {
            'application':'regression',
            'num_iterations': n_estimators,
            'learning_rate':learning_rate,
            'early_stopping_round':100,
            'metric':'rmse'
            }

        params["num_leaves"] = int(round(num_leaves))
        params['feature_fraction'] = max(min(feature_fraction, 1), 0)
        params['bagging_fraction'] = max(min(bagging_fraction, 1), 0)
        params['max_depth'] = int(round(max_depth))
        params['lambda_l1'] = max(lambda_l1, 0)
        params['lambda_l2'] = max(lambda_l2, 0)
        params['min_split_gain'] = min_split_gain
        params['min_child_weight'] = min_child_weight

        cv_result = lgb.cv(
            params, train_data,
            nfold=n_folds,
            seed=random_seed,
            stratified=False,
            verbose_eval =200,
            metrics=['rmse']
            )

        return max(cv_result['rmse-mean'])

    lgbBO = BayesianOptimization(lgb_eval,
                                            {'num_leaves': (24, 45),
                                            'feature_fraction': (0.1, 0.9),
                                            'bagging_fraction': (0.8, 1),
                                            'max_depth': (5, 8.99),
                                            'lambda_l1': (0, 5),
                                            'lambda_l2': (0, 3),
                                            'min_split_gain': (0.001, 0.1),
                                            'min_child_weight': (5, 50)}, random_state=0)
    # optimize
    lgbBO.maximize(init_points=init_round, n_iter=opt_round)

    # output optimization process
    if output_process==True: lgbBO.points_to_csv("bayes_opt_result.csv")

    # return best parameters
    return lgbBO.res[0]["params"]
opt_params = bayes_parameter_opt_lgb(
                                    X_train_ce,
                                    y_train,
                                    init_round=5,
                                    opt_round=10,
                                    n_folds=3,
                                    random_seed=SEED,
                                    n_estimators=100,
                                    learning_rate=0.05
                                    )

y_train = y_train.reset_index(drop=True)

gkf = GroupKFold(n_splits=5)

groups = X_train_ce["Genre"]

lgb_results = {}                                    # 学習の履歴を入れる入物

opt_params["application"] = "regression" # 回帰を追加
opt_params["metrics"] = "rmse" # 評価指標を追加
opt_params["num_leaves"] = int(round(opt_params["num_leaves"])) # 整数に変換
opt_params["max_depth"] = int(round(opt_params["max_depth"])) # 整数に変換

cv_result_bayes = []

for train_index, test_index in gkf.split(X_train_ce, y_train, groups):
    X_train_gkf, X_test_gkf = X_train_ce.iloc[train_index], X_train_ce.iloc[test_index]
    y_train_gkf, y_test_gkf = y_train.iloc[train_index], y_train.iloc[test_index]

    # データセットを登録
    lgb_train = lgb.Dataset(X_train_gkf, y_train_gkf)
    lgb_test = lgb.Dataset(X_test_gkf, y_test_gkf, reference=lgb_train)

    lgb_results = {}                                    # 学習の履歴を入れる入物

    model = lgb.train(
                    params=opt_params,           # ベストパラメータをセット
                    train_set=lgb_train,              # 訓練データを訓練用にセット
                    valid_sets=[lgb_train, lgb_test], # 訓練データとテストデータをセット
                    valid_names=['Train', 'Test'],    # データセットの名前をそれぞれ設定
                    num_boost_round=100,              # 計算回数
                    early_stopping_rounds=50,         # アーリーストッピング設定
                    evals_result=lgb_results,
                    verbose_eval=-1,                           # ログを最後の1つだけ表示
                    )

    # 損失推移を表示
    loss_train = lgb_results['Train']['rmse']
    loss_test = lgb_results['Test']['rmse']

    fig = plt.figure()

    plt.xlabel('Iteration')
    plt.ylabel('logloss')

    plt.title(f"fold:{fold}")
    plt.plot(loss_train, label='train loss')
    plt.plot(loss_test, label='test loss')

    plt.legend()
    plt.show()

    # 推論
    y_pred = model.predict(X_test_gkf)

    # 評価
    rmse = mean_squared_error(y_test_gkf, y_pred, squared=False)
    cv_result_bayes.append(rmse)

print("RMSE:", cv_result_bayes)
print("RMSE:", np.mean(cv_result_bayes))

Optuna による最適化との比較

Optuna による最適化についてはここでは割愛

https://zenn.dev/megane_otoko/articles/2021ad_09_optuna_optimization
print("Optuna RMSE:", round(np.mean(cv_result_opt), 3), "経過時間:", elasp_time_opt, "秒")
print("ベイズ最適化 RMSE:", round(np.mean(cv_result_bayes), 3), "経過時間:", elasp_time_bayes, "秒")

精度は Optuna に負けますが、処理時間は圧倒的にベイズ最適化のほうが短いですね。

内訳 RMSE 経過時間
Optuna最適化 0.186 187.2秒
ベイズ最適化 0.209 13.9 秒

10日目は以上になります、最後までお読みいただきありがとうございました。

参考情報

https://github.com/fmfn/BayesianOptimization
https://www.kaggle.com/sz8416/simple-bayesian-optimization-for-lightgbm
