NixOS on Lima

NixOS
Lima
Hidekazu TanakaHidekazu Tanaka

https://github.com/nixos-lima/nixos-lima-config-sample/blob/f25c9085502364bba1582e12fcec8e8b7dcec262/nixos.yaml

この設定ファイルを参考に、次の設定ファイルを作成した。

images:
  - location: https://s3.us-west-2.amazonaws.com/static.msgilligan.com/nixos-lima/nixos-lima-unstable-aarch64.qcow2
    arch: aarch64
    digest: sha512:51529441cec5b90c3772f81ec5cfc09c6ce4534ac76e7cb8415df754900cc2250947df59c327d9c7dbbcb95a3dc317f0c8c55fdd3c7c00740693c3cc437f7fce
  - location: https://s3.us-west-2.amazonaws.com/static.msgilligan.com/nixos-lima/nixos-lima-unstable-x86_64.qcow2
    arch: x86_64
    digest: sha512:5492489506bb14ace363f83d30425db48a01c379bb39a3787b914c9eac754e59326a5b424866f423c2d2e0358d0975bbf94a1cf3914e91654cc399daea1f0fe5
ssh:
  forwardAgent: true
containerd:
  user: false

この設定ファイルで起動すると……、

$ limactl start --name=nixos --tty=false configs/lima/nixos.yaml
INFO[0000] Terminal is not available, proceeding without opening an editor
INFO[0000] Starting the instance "nixos" with VM driver "vz"
INFO[0000] Attempting to download the image              arch=aarch64 digest="sha512:51529441cec5b90c3772f81ec5cfc09c6ce4534ac76e7cb8415df754900cc2250947df59c327d9c7dbbcb95a3dc317f0c8c55fdd3c7c00740693c3cc437f7fce" location="https://s3.us-west-2.amazonaws.com/static.msgilligan.com/nixos-lima/nixos-lima-unstable-aarch64.qcow2"
Downloading the image (nixos-lima-unstable-aarch64.qcow2)
2.37 GiB / 2.37 GiB [---------------------------------------] 100.00% 2.20 MiB/s
INFO[1105] Downloaded the image from "https://s3.us-west-2.amazonaws.com/static.msgilligan.com/nixos-lima/nixos-lima-unstable-aarch64.qcow2"
INFO[1108] [hostagent] hostagent socket created at /Users/hidekazu/.lima/nixos/ha.sock
INFO[1108] [hostagent] Starting VZ (hint: to watch the boot progress, see "/Users/hidekazu/.lima/nixos/serial*.log")
INFO[1109] SSH Local Port: 58623
INFO[1108] [hostagent] Waiting for the essential requirement 1 of 2: "ssh"
INFO[1108] [hostagent] [VZ] - vm state change: running
INFO[1118] [hostagent] Waiting for the essential requirement 1 of 2: "ssh"
INFO[1122] [hostagent] 2025/07/17 20:17:45 tcpproxy: for incoming conn 127.0.0.1:58627, error dialing "192.168.5.15:22": connect tcp 192.168.5.15:22: no route to host
INFO[1131] [hostagent] Waiting for the essential requirement 1 of 2: "ssh"
INFO[1135] [hostagent] 2025/07/17 20:17:58 tcpproxy: for incoming conn 127.0.0.1:58631, error dialing "192.168.5.15:22": connect tcp 192.168.5.15:22: no route to host
INFO[1144] [hostagent] Waiting for the essential requirement 1 of 2: "ssh"
INFO[1148] [hostagent] 2025/07/17 20:18:11 tcpproxy: for incoming conn 127.0.0.1:58632, error dialing "192.168.5.15:22": connect tcp 192.168.5.15:22: no route to host
INFO[1157] [hostagent] Waiting for the essential requirement 1 of 2: "ssh"
INFO[1161] [hostagent] 2025/07/17 20:18:24 tcpproxy: for incoming conn 127.0.0.1:58638, error dialing "192.168.5.15:22": connect tcp 192.168.5.15:22: no route to host
INFO[1170] [hostagent] Waiting for the essential requirement 1 of 2: "ssh"
INFO[1174] [hostagent] 2025/07/17 20:18:38 tcpproxy: for incoming conn 127.0.0.1:58642, error dialing "192.168.5.15:22": connect tcp 192.168.5.15:22: no route to host
INFO[1184] [hostagent] Waiting for the essential requirement 1 of 2: "ssh"
INFO[1187] [hostagent] 2025/07/17 20:18:51 tcpproxy: for incoming conn 127.0.0.1:58644, error dialing "192.168.5.15:22": connect tcp 192.168.5.15:22: no route to host
INFO[1197] [hostagent] Waiting for the essential requirement 1 of 2: "ssh"
INFO[1200] [hostagent] 2025/07/17 20:19:04 tcpproxy: for incoming conn 127.0.0.1:58645, error dialing "192.168.5.15:22": connect tcp 192.168.5.15:22: no route to host
INFO[1210] [hostagent] Waiting for the essential requirement 1 of 2: "ssh"
INFO[1213] [hostagent] 2025/07/17 20:19:17 tcpproxy: for incoming conn 127.0.0.1:58650, error dialing "192.168.5.15:22": connect tcp 192.168.5.15:22: no route to host

起動しなかった……。

Hidekazu TanakaHidekazu Tanaka

vmType を qemu にしたところ、無事に起動した。

$ limactl start --name=nixos-qemu --tty=false --set '.vmType = "qemu"' configs/lima/nixos.yaml
INFO[0000] Terminal is not available, proceeding without opening an editor
INFO[0000] Starting the instance "nixos-qemu" with VM driver "qemu"
INFO[0000] QEMU binary "/opt/homebrew/bin/qemu-system-aarch64" seems properly signed with the "com.apple.security.hypervisor" entitlement
INFO[0000] Attempting to download the image              arch=aarch64 digest="sha512:51529441cec5b90c3772f81ec5cfc09c6ce4534ac76e7cb8415df754900cc2250947df59c327d9c7dbbcb95a3dc317f0c8c55fdd3c7c00740693c3cc437f7fce" location="https://s3.us-west-2.amazonaws.com/static.msgilligan.com/nixos-lima/nixos-lima-unstable-aarch64.qcow2"
INFO[0000] Using cache "/Users/hidekazu/Library/Caches/lima/download/by-url-sha256/4209ac5c300499c8462b5b538ab9ae18b21c2f3babd471b34d6b423f8f62841f/data"
INFO[0000] [hostagent] hostagent socket created at /Users/hidekazu/.lima/nixos-qemu/ha.sock
INFO[0000] [hostagent] Using system firmware ("/opt/homebrew/share/qemu/edk2-aarch64-code.fd")
INFO[0000] [hostagent] Starting QEMU (hint: to watch the boot progress, see "/Users/hidekazu/.lima/nixos-qemu/serial*.log")
INFO[0000] SSH Local Port: 58737
INFO[0000] [hostagent] Waiting for the essential requirement 1 of 2: "ssh"
INFO[0010] [hostagent] Waiting for the essential requirement 1 of 2: "ssh"
INFO[0017] [hostagent] The essential requirement 1 of 2 is satisfied
INFO[0017] [hostagent] Waiting for the essential requirement 2 of 2: "user session is ready for ssh"
INFO[0017] [hostagent] The essential requirement 2 of 2 is satisfied
INFO[0017] [hostagent] Waiting for the guest agent to be running
INFO[0017] [hostagent] Forwarding "/run/lima-guestagent.sock" (guest) to "/Users/hidekazu/.lima/nixos-qemu/ga.sock" (host)
INFO[0017] [hostagent] Guest agent is running
INFO[0017] [hostagent] Waiting for the final requirement 1 of 1: "boot scripts must have finished"
INFO[0017] [hostagent] Not forwarding TCP 0.0.0.0:22
INFO[0017] [hostagent] Not forwarding TCP [::]:22
INFO[0017] [hostagent] Not forwarding UDP 0.0.0.0:68
INFO[0017] [hostagent] The final requirement 1 of 1 is satisfied
INFO[0018] READY. Run `limactl shell nixos-qemu` to open the shell.
Hidekazu TanakaHidekazu Tanaka
git diff lima.nix
diff --git a/lima.nix b/lima.nix
index 9acc2ba..ef8bb31 100644
--- a/lima.nix
+++ b/lima.nix
@@ -19,10 +19,13 @@
     };

     # system mounts
-    boot.loader.grub = {
-        device = "nodev";
-        efiSupport = true;
-        efiInstallAsRemovable = true;
+    boot = {
+        kernelParams = [ "console=tty0" ];
+        loader.grub = {
+            device = "nodev";
+            efiSupport = true;
+            efiInstallAsRemovable = true;
+        };
     };
     fileSystems."/boot" = {
         device = lib.mkForce "/dev/vda1";  # /dev/disk/by-label/ESP

起動はできた！

Hidekazu TanakaHidekazu Tanaka

lima-guestagent は起動している。

$ sudo systemctl status lima-guestagent.service
● lima-guestagent.service - Forward ports to the lima-hostagent
     Loaded: loaded (/etc/systemd/system/lima-guestagent.service; enabled; preset: ignored)
     Active: active (running) since Sat 2025-07-19 00:38:20 UTC; 2min 1s ago
 Invocation: 934667db41814d0c8db3fc9f4cbfc037
   Main PID: 911 (lima-guestagent)
         IP: 0B in, 0B out
         IO: 29.2M read, 0B written
      Tasks: 7 (limit: 4613)
     Memory: 34.9M (peak: 35.6M)
        CPU: 30ms
     CGroup: /system.slice/lima-guestagent.service
             └─911 /mnt/lima-cidata/lima-guestagent daemon

Jul 19 00:38:20 nixos systemd[1]: Started Forward ports to the lima-hostagent.
Jul 19 00:38:20 nixos lima-guestagent[911]: time="2025-07-19T00:38:20Z" level=info msg="event tick: 3s"
Jul 19 00:38:20 nixos lima-guestagent[911]: time="2025-07-19T00:38:20Z" level=info msg="Enabling auditing"
Jul 19 00:38:20 nixos lima-guestagent[911]: time="2025-07-19T00:38:20Z" level=info msg="Auditing enabled (0)"
Jul 19 00:38:20 nixos lima-guestagent[911]: time="2025-07-19T00:38:20Z" level=info msg="serving the guest agent on \"/run/lima-guestagent.sock\""
Jul 19 00:38:20 nixos lima-guestagent[911]: time="2025-07-19T00:38:20Z" level=info msg="fixSystemTimeSkew(): monitoring system time skew"
Jul 19 00:38:20 nixos lima-guestagent[911]: time="2025-07-19T00:38:20Z" level=info msg="setWorthCheckingIPTablesRoutine(): monitoring netfilter >
Jul 19 00:38:20 nixos lima-guestagent[911]: time="2025-07-19T00:38:20Z" level=info msg="Monitoring kubernetes services"

$ sudo /mnt/lima-cidata/lima-guestagent --help
Do not launch manually

Usage:
  lima-guestagent [command]

Available Commands:
  completion      Generate the autocompletion script for the specified shell
  daemon          Run the daemon
  help            Help about any command
  install-systemd Install a systemd unit (user)

Flags:
      --debug     Debug mode
  -h, --help      help for lima-guestagent
  -v, --version   version for lima-guestagent

Use "lima-guestagent [command] --help" for more information about a command.

$ sudo /mnt/lima-cidata/lima-guestagent daemon --help
Run the daemon

Usage:
  lima-guestagent daemon [flags]

Flags:
  -h, --help                 help for daemon
      --tick duration        Tick for polling events (default 3s)
      --virtio-port string   Use virtio server instead a UNIX socket
      --vsock-port int       Use vsock server instead a UNIX socket

Global Flags:
      --debug   Debug mode

--vsock-port が指定されていないのが原因？

Hidekazu TanakaHidekazu Tanaka
git diff lima-init.nix
diff --git a/lima-init.nix b/lima-init.nix
index 25fdf94..e602fb9 100644
--- a/lima-init.nix
+++ b/lima-init.nix
@@ -143,7 +143,7 @@ in {
             requires = [ "lima-init.service" ];
             serviceConfig = {
                 Type = "simple";
-                ExecStart = "${LIMA_CIDATA_MNT}/lima-guestagent daemon";
+                ExecStart = "${LIMA_CIDATA_MNT}/lima-guestagent daemon --vsock-port 2222";
                 Restart = "on-failure";
             };
         };
@@ -159,7 +159,7 @@ in {
         };

         networking.nat.enable = true;
-
+
         environment.systemPackages = with pkgs; [
             bash
             sshfs

イメージを再ビルドしたら、期待通りに起動できた！

$ git diff lima-init.nix
diff --git a/lima-init.nix b/lima-init.nix
index 25fdf94..e602fb9 100644
--- a/lima-init.nix
+++ b/lima-init.nix
@@ -143,7 +143,7 @@ in {
             requires = [ "lima-init.service" ];
             serviceConfig = {
                 Type = "simple";
-                ExecStart = "${LIMA_CIDATA_MNT}/lima-guestagent daemon";
+                ExecStart = "${LIMA_CIDATA_MNT}/lima-guestagent daemon --vsock-port 2222";
                 Restart = "on-failure";
             };
         };
@@ -159,7 +159,7 @@ in {
         };

         networking.nat.enable = true;
-
+
         environment.systemPackages = with pkgs; [
             bash
             sshfs
このスクラップは1ヶ月前にクローズされました
